100S (JHMGC100S ) HDPE resin, independently developed and produced by PetroChina Jilin Petrochemical, is a special material for bimodal high-density polyethylene (HDPE) pipes. This resin utilizes Jilin Petrochemical’s mature gas-phase polymerization process, precisely controlling the bimodal molecular weight distribution and comonomer ratio. It overcomes the performance limitations of traditional polyethylene materials, balancing high strength, high toughness, and excellent processability. The quality of Jihua JHMGC100S PE100 resin is stable and reliable, making it a preferred raw material for manufacturing high-end pressure-bearing plastic pipes.
PetroChina Jihua JHMGC100S PE100 resin TDS & Specification
| Item | Unit | Typical values |
| Melt Flow Rate | g/10min, 5kg | 0.22 |
| Density | g/cm³ | 0.950 |
| Nominal tensile strain at break | % | 700 |
| Tensile streagth at yield | Mpa | 22.8 |
Excellent Performance of HDPE 100S
- Superior pressure resistance and creep resistance, long and stable service life
This resin possesses excellent long-term hydrostatic strength and creep resistance. Under standard pressure conditions of 20℃ and 10.0 MPa, it can stably maintain its performance for 50 years without failure or deformation, perfectly adapting to various high-pressure pipeline scenarios.
- Dual crack resistance, adaptable to complex and harsh working conditions
HDPE 100S possesses excellent resistance to both slow crack growth (SCG) and rapid crack propagation (RCP), exhibiting superior resistance to environmental stress cracking. Under complex conditions such as slight foundation settlement, pipe bending, low-temperature environments, and corrosive media, it is less prone to micro-cracks and effectively prevents crack propagation.
- Corrosion and weather resistance, suitable for multi-media transportation
100S PE100 resin exhibits extremely strong chemical stability, resisting acids, alkalis, salt spray, and sewage corrosion. It does not react with domestic sewage, corrosive industrial fluids, seawater, or other media, and will not experience rusting, aging, or leakage. It also possesses excellent low-temperature resistance and aging resistance, resisting UV radiation and weathering during long-term outdoor use.
- Excellent processing performance, suitable for large-diameter pipe production
The HDPE 100S resin boasts stable melt flow properties, outstanding anti-sagging characteristics, smooth extrusion molding process, uniform plasticization, and extremely high processing stability. It can be used not only for the conventional production of small and medium diameter pipes, but also for the large-scale production of large-diameter, thick-walled pipes over 800 mm. It can meet the mass production needs of large-scale municipal projects and large-scale water and gas transmission pipelines.
What Are Main Applications of JHMGC100S PE100 Resin?
- Municipal water supply and drainage engineering.
With its advantages of being non-toxic and environmentally friendly, pressure-resistant, leak-proof, and having a long service life, it is the preferred raw material for municipal water supply, building water supply and drainage, and urban stormwater drainage pipelines. It is also suitable for seawater desalination and coastal water transmission projects, as it can withstand seawater corrosion and solve the problem of corrosion and aging in coastal pipeline networks.
- Gas transmission and distribution engineering
With its extreme crack resistance, high pressure resistance, and leak-proof performance, it fully meets the stringent safety standards for natural gas, residential gas, and industrial gas transmission pipelines. It can effectively avoid the risk of gas leaks and is suitable for urban gas main networks, residential pipe networks, and industrial gas transmission pipelines.
- Heating and cooling engineering
JHMGC100S PE100 resin possesses excellent creep resistance and thermal stability, capable of withstanding long-term thermal cycling in heating systems. Even under repeated temperature increases and decreases, it maintains dimensional stability, remains undeformed, and leak-proof, making it widely applicable in municipal centralized heating networks, building underfloor heating pipes, and industrial heating pipelines.
- Modern agricultural industry
With its corrosion resistance, aging resistance, high flexibility, and ease of construction, it is widely used in farmland water-saving irrigation pipelines, greenhouse water supply pipelines, and aquaculture water supply pipelines.
- Industrial and power supporting industries
It can be used to produce protective conduits for electrical wires and cables, industrial corrosive media transport pipelines, and industrial sewage pipelines. Pipes manufactured from it can safely transport mildly corrosive chemical fluids and industrial wastewater, and are suitable for the construction of supporting pipeline networks in various industrial plants.
